PFsense HAProxy with 1 certificate 2 domains

Networking & Firewalls
1

I am new to PFsense and HAProxy and need your help with the following:

I successfully configured HAProxy on PFsense with an ACME certificate with a SAN List for the domains “A.COM” and “.B.COM” with wildcards. I have 3 backends for the domain A.COM and 1 for B.COM. They are all assigned to a single frontend. When accessing the domain A.COM, everything works correctly, but for B.COM, the certificate is not assigned properly.

Is it possible for HAProxy to handle a single certificate for two domains?
How can I make HAProxy work in this situation?

2

I think you can only have one Wildcard cert per front end.

3

Thanks for quick answer
So, the solution, is to create a cert for each domain and add them do the frontend in additional certificates?

4

I have never tested this setup but there is an older write up on using HAProxy with one front end and multiple domains.

5

This should work with multiple wildcard SANs in one cert, and in additional certs for that matter. But double check you’ve enabled the SAN list ACLs on the frontend though.

  • Frontend
    • SSL Offloading
      • Certificate
        • Add ACL for certificate CommonName
        • Add ACL for certificate Subject Alternative Names

Same can be done for Additional certificates a section or two below.

6

First of all, my thanks to everyone for their help.
I managed to get it working.
I have three sites with different domains under a single certificate.
The problem was not with HAProxy, but with the Vhost file for each site.
