OpenVPN - not routing Internet traffic?

Networking & Firewalls
1

I am trying to set up a simple VPN at home with my pfSense 1100g. I want all traffic routed thru the VPN.

The behavior that I’m getting is that the VPN connects, I’m able to access site-local resources, but unable to route to the Internet.

I can ping everything internal, all servers and services, DNS is working within the tunnel. I just can’t get Internet things to work.

pfSense is running the latest version.
Latest version of Windows OpenVPN as a client.
Lastest version of OpenVPN Connect on both Android and iPhone as well.

Firewall rules:
OpenVPN interface

States 		Protocol 	Source 		Port 	Destination 	Port 	Gateway 	Queue 	Schedule 	Description
0/0 B		IPv4 * 		pfB_Top_v4	*		* 				* 		*			none 	 			pfB_Top_v4 auto rule
0/10 KiB	IPv4 * 	* 	* 	pfB_Top_v4 	* 	* 	none 	  	pfB_Top_v4 auto rule
0/0 B		IPv4 * 	* 	* 	pfB_PRI1_v4 	* 	* 	none 	  	pfB_PRI1_v4 auto rule
0/0 B		IPv4 ICMP	any			* 		* 	* 	* 	* 	none 	  	ICMP from OpenVPN
0/995 KiB	IPv4 UDP 	* 			* 		* 				53 (DNS) 	* 	none 	  	DNS from OpenVPN
		0/0 B
	IPv4 TCP 	* 	* 	* 	80 (HTTP) 	* 	none 	  	HTTP from OpenVPN
		0/0 B
	IPv4 TCP 	* 	* 	* 	443 (HTTPS) 	* 	none 	  	HTTP from OpenVPN
		0/44.55 MiB
	IPv4 * 	* 	* 	* 	* 	WAN_DHCP 	none 	  	Allow OpenVPN Out
		0/0 B
	IPv4 * 	* 	* 	* 	* 	* 	none 	  	OpenVPN HomeVPN-new wizard

( tried forcing use of the WAN_DHCP gateway in case that was the issue )

WAN interface:

 		States 	Protocol 	Source 	Port 	Destination 	Port 	Gateway 	Queue 	Schedule 	Description 	Actions
		0/44.05 MiB	* 	RFC 1918 networks 	* 	* 	* 	* 	* 		Block private networks
		0/23 KiB	* 	Reserved
Not assigned by IANA 	* 	* 	* 	* 	* 		Block bogon networks
		0/24.24 MiB	IPv4 * 	pfB_Top_v4 	* 	* 	* 	* 	none 	  	pfB_Top_v4 auto rule
		0/181 KiB	IPv4 TCP 	* 	* 	WAN address 	1195 	* 	none 	  	OpenVPN HomeVPN-new wizard
		0/73.10 MiB	IPv4 UDP 	* 	* 	WAN address 	1194 (OpenVPN) 	* 	none 	  	OpenVPN HomeVPN wizard
		0/7 KiB	IPv4 TCP 	* 	* 	* 	22 (SSH) 	* 	none 	  	Explicit Block: SSH >> WAN
		0/750 B	IPv4 TCP/UDP 	* 	* 	* 	5353 	* 	none 	  	Drop MDNS silently
		0/322 KiB	IPv4 TCP 	* 	* 	172.16.90.254 	80 (HTTP) 	* 	none 	  	NAT Redirect HTTP to HTTPS in DMZ
		0/10.48 MiB	IPv4 TCP 	* 	* 	172.16.90.254 	443 (HTTPS) 	* 	none 	  	NAT HTTPS Forward to DMZ
		0/649 KiB	IPv4 TCP 	* 	* 	* 	* 	* 	none 	  	WAN TCP Connection Blocked
		0/665 KiB	IPv4 UDP 	* 	* 	* 	* 	* 	none 	  	WAN UDP Connection Blocked
		0/203 KiB	IPv4+6 * 	* 	* 	* 	* 	* 	none 	  	WAN - Unsupported Protocol Blocked

Most of those are commented enough to be straightforward, lmk if there’s anything weird looking.

server config:

dev ovpns2
disable-dco
verb 4
dev-type tun
dev-node /dev/tun2
writepid /var/run/openvpn_server2.pid
#user nobody
#group nobody
script-security 3
daemon
keepalive 10 60
ping-timer-rem
persist-tun
persist-key
proto tcp4-server
auth SHA256
up /usr/local/sbin/ovpn-linkup
down /usr/local/sbin/ovpn-linkdown
client-connect /usr/local/sbin/openvpn.attributes.sh
client-disconnect /usr/local/sbin/openvpn.attributes.sh
learn-address "/usr/local/sbin/openvpn.learn-address.sh the.domain"
local myactualip
tls-server
server 192.168.110.0 255.255.255.0
client-config-dir /var/etc/openvpn/server2/csc
plugin /usr/local/lib/openvpn/plugins/openvpn-plugin-auth-script.so /usr/local/sbin/ovpn_auth_verify_async user somestringhere false server2 1195
tls-verify "/usr/local/sbin/ovpn_auth_verify tls 'the.domain.com' 1"
lport 1195
management /var/etc/openvpn/server2/sock unix
max-clients 6
push "dhcp-option DOMAIN the.domain"
push "dhcp-option DNS 172.16.30.1"
push "block-outside-dns"
push "register-dns"
push "dhcp-option NTP 172.16.30.1"
push "redirect-gateway def1"
capath /var/etc/openvpn/server2/ca
cert /var/etc/openvpn/server2/cert
key /var/etc/openvpn/server2/key
dh /etc/dh-parameters.4096
tls-auth /var/etc/openvpn/server2/tls-auth 0
data-ciphers CHACHA20-POLY1305
data-ciphers-fallback CHACHA20-POLY1305
allow-compression no
persist-remote-ip
float
topology subnet
inactive 300
tun-mtu 1450

mssfix 1420

example client config:

dev tun
persist-tun
persist-key
data-ciphers CHACHA20-POLY1305
data-ciphers-fallback CHACHA20-POLY1305
auth SHA256
tls-client
client
resolv-retry infinite
remote myactualip 1195 tcp4
nobind
verify-x509-name "the.domain.com" name
auth-user-pass
remote-cert-tls server
<ca>
 ... ca ...
</ca>
<cert>
 ... cert ...
</cert>
<key>
 ... key ...
</key>
key-direction 1
<tls-auth>
 ... key ...
</tls-auth>

Does anyone see any issues…? I’m stumped.

I can also post pictures of the pfSense settings if that’s easier and allowed. lmk!

Any help is very much appreciated!

( in the process of editing the firewall rules for more clarity )

2

To get all traffic to route make sure you have the correct rules in the pfesnes and in the OpenVPN server settings that you have “Redirect IPv4 Gateway” “Force all client-generated IPv4 traffic through the tunnel.” checked.

This is my latest guide for OpenVPN on pfsense

3

Hi there! Exciting to hear from you :slight_smile: love all your videos.

I just got it working!

Since I kept banging my head against the problem, I was considering switching to Wireguard. Your video on that points out the need for outbound NAT for the Wireguard network - which I was able to do for OpenVPN, and it works!

1 Like
